1-1/2" NON-RETENTION SANITARY BALL VALVE, 3 PIECES, 304 STAINLESS STEEL
Applications:
The hygienic design of the valve is widely used in the field of food processing, beverages, and biopharmaceutical for shut-off fluids, gases, and steam. Are ideal for applications requiring a full flow body design to minimize line turbulence and pressure drop .
Features:
?¡è??????? Fully encapsulated or cavity filled with PTFE, 3A and FDA certificated .
?¡è??????? ISO 5211 Mounting Pad
?¡è??????? High pressure applications
?¡è??????? Full Port design
?¡è??????? The design allows for serviceability without removing the complete valve from the line
Technical Specifications:
?¡è??????? Size: 1"- 4"
?¡è??????? Body Material: Stainless steel 304 or 316
?¡è??????? 2 Way or 3 way
?¡è??????? Clamp connection
?¡è??????? Max pressure: 600 PSI WOG
?¡è??????? Working temperature: -65 Degrees to 300 Degrees F
?¡è??????? Surface finish: All surfaces which come directly or indirectly in contact with the product are machined to 0.625 micron (25 micro inch Ra, 180 Grit).
?¡è??????? Seal material: PTFE
?¡è??????? Stem material: SS 304 /316
