Sanitary SS 304 3A -2LBS Update Kit Closed Loop Extractor 6IN
Closed Loop Reclamation Extraction System (Comes with 1 yr. Limited warranty) 150 Micron Mesh Blast tube Filter Nitrile Buna-N Gaskets are designed for Oil Processing Temp range -30-200F full set of extra gaskets including the 150 micron mesh gasket for the blast tube is included.
304 Stainless Steel Blast Tube 3x18" 2LBS
304 Stainless Steel Base Container 12" diameter by 12" tall
304 Stainless Steel Heavy Duty Ball Valves
2 pc insight glass
System Rated to 100PSI for blasting
Multiple port connections for " ACME
Vacuum clamps at all interfaces make for a high pressure, easy clean unit.
1 pc Vacuum gauge
Dimensions (Inches): 25" x 7" Diameter overall size
Weight: 21 lbs.
Operating Temperature Range: 0C (32F) to 72C (160F)
Ultimate Vacuum: as low as 10 Microns
Base unit Maximum Capacity: 155 cubic inches, (2.553 Liters)
Construction: All components made of 304 Stainless Steel.
Intake Fittings: " ACME Vacuum Fittings
Max Vacuum -29.9inHg
High Polish Interior base
Material: Stainless Steel
Wall Density (MM): 3
Max Temp. (F): 250
Max Pressure (PSI): 100
Connection Type: MJIC
Diameter (IN): 6
Height (IN): 60
Radius (IN): 3
Volume (Cu In): 1695.6
Butane Capacity (LBS): 30.00 - 37.50
Propane Capacity (LBS): 23.75 - 29.69
Biomass Capacity (LBS): 8.75 - 12.50
Fluid Capacity (L): 27.76
Fluid Capacity (Gal): 7.34
"HFS uses testing methods that focus on pressure-dependent leaks and microleaks to ensure that all systems function as safe and efficient as possible.?
We inject 100 PSI of AIR +? 50 PSI NITROGEN and hold for 30-45 min.? "
