Heated Circulator Standard Digital, Ambient +5 to 200 deg C, 220V

HFS SKU: HEATER-SC-15L-100
Heated Circulator Standard Digital, Ambient +5 to 200 deg C, 220V
Heated Circulator Standard Digital, Ambient +5 to 200 deg C, 220V
Heated Circulator Standard Digital, Ambient +5 to 200 deg C, 220V
Heated Circulator Standard Digital, Ambient +5 to 200 deg C, 220V
Heated Circulator Standard Digital, Ambient +5 to 200 deg C, 220V
Hardware Factory Store Inc - Liquid Circulating Heaters - [variant_title]

Heated Circulator Standard Digital, Ambient +5 to 200 deg C, 220V

HFS SKU: HEATER-SC-15L-100
Size
Regular price $999.00
/
Only 25 items in stock!
  • We currently only offer shipping to addresses within the US
  • Free returns
  • Sustainably made
  • Secure payments

CLICK HERE TO DOWNLOAD MANUAL

WARNING: To reduce the risk of injury, do not attempt to use or maintain this unit until you read and understand the instructions. Do not permit untrained persons to use or maintain this unit.

Features:

(1) Low TemperatureCoolantcirculator is used wind-cool-type and complete-close-compressor set to refrigerate. By microprocessor control, cooling systems. automatically start, time-lapse turn off, with over-heat and over-current protection

(2) The Circulator may export the coolant from reservoir, cool or maintain the temperature outside the laboratory container or establish a second constant temperature field.

(3) Microprocessor controls the time switchfrom 0-100 hours.

(4) Dual windows, Red and Green Touch display the set temperature and the actualtemperature, respectively. The readout accuracy is ±0.1°C, and the stability is ± 0.1°C.

(5) Microprocessor-controlled-lock function may lock all parameters.

(6) Having Easy-to-usemicroprocessor controltouch keys.

Technical data:

Model

HEATER-SC-15L-100

HEATER-SC-15L-200

HEATER-SC-30L-200

Tem. range ()

RT+5~100

RT+5~200

RT+5~200

Tem. volatility ()

±0.05~±0.2

±0.05~±0.2

±0.05~±0.2

Display resolution (mm³)

0.1

0.1

0.1

Tank size (mm)

300*240*200

300*240*200

400*330*230

Tank depth (mm)

200

200

230

Pump flow (L/min)

0-20

Cycle

Cycle

Tank open size (mm²)

235*160

235*160

310*280

Drainage

Y

NO

NO

Operatioin voltage (V)

110

220

220

Power (W)

1000

2980

4500


      Display:

       HEATER-SC Interface

      (1) Refrigeration lightRefrigeration light: When the light flashing refrigeration is on, the cooling function start working after 2-3 minutes, Refrigeration lights long time bright.

      (2) Circulating pump lightCirculating pump light: When long press the RUN key button machine, circulating pump auto working, when shut off, the light dark.

      (3) Heating lightHeating light: Start heat function, the light on, or it’s off.

      (4) Water lever lightWater lever light: The light tip groove liquid lever cannot under working table 30mm.

      (5) RUN key: Long press 5 second, the device start or stop working .

      (6) SET keySET key: TEM Setting and TEM Measure set confirm, and amend etc.

      (7) LEFT MOVE KeyLEFT MOVE Key: SETTING data move key.

      (8) UP and DOWN KeyUP and DOWN Key: SETTING DATA “+”or “-” Long press UP key, can be check environment temperature.

      Notice: If TEM Measure area display “” indicate sensor input or the signal over measurement limit, if display “”, indicate sensor short circuit or the input signal is lower than the lower limited range when the input signal is beyond the scope of range, buzzer, press any key be muted.

      Tech Tip:

      (1) Before using, should add full liquidmedium.

      (2) The power supply should be match with the technical parameter. The power should be greater than or equalto the total power of the machine. Ground wireshould be used (Connect the snail located at the left bottom on the rear side).

      (3) The machineshould be put in dry anddrafty place, rear and two sides 400mm apart from other articles.

      (4) After done, all switchesshould be in turn off,Pull out plug, dry and clean bath.

          Packing list:

          1. Main machine

          1set

          2. Power supply wire

          1pc    

          3. Rubber tube

          1pc

          4. Cover

          1pc

          5. Operational Manual

          1copy
