1 Pair 123 Blocks 1-2-3 Ultra Precision .0002 Hardened 23 Holes 0.0002"

HFS SKU: BLOCK123-LS-1x2
1 Pair 123 Blocks 1-2-3 Ultra Precision .0002 Hardened 23 Holes 0.0002"

1 Pair 123 Blocks 1-2-3 Ultra Precision .0002 Hardened 23 Holes 0.0002"

HFS SKU: BLOCK123-LS-1x2
Regular price $19.99 Sale price $18.09 Save $1.90
/
  • We currently only offer shipping to addresses within the US
  • Free returns
  • Sustainably made
  • Secure payments
Size within +/- .0002"
Flatness and parallelism within .0002"
Squareness on all sides is 0.0003" per inch
Pairs are matched to a tolerance of 0.0002"

Product application
Used for set-up. layout and inspection jobs

Product features
Has 23 holes with 5 holes tap to 3/8-16 threads for clamping and 18 untapped holes
Made of hardened tool steel and precision ground on all six sides
Cross drilling design allows efficient use of lower weight with maximum strength
Heat treat and hardness 56 to 60 RC
2 pieces per set
Weight: 2.1 Lbs
