160 L, (175 lbs. Refrigerant), Jacketed Storage Vessel With Condenser

HFS SKU: EXA-TANK16X48-COIL-0102
160 L, (175 lbs. Refrigerant), Jacketed Storage Vessel With Condenser
160 L, (175 lbs. Refrigerant), Jacketed Storage Vessel With Condenser
160 L, (175 lbs. Refrigerant), Jacketed Storage Vessel With Condenser
160 L, (175 lbs. Refrigerant), Jacketed Storage Vessel With Condenser

160 L, (175 lbs. Refrigerant), Jacketed Storage Vessel With Condenser

HFS SKU: EXA-TANK16X48-COIL-0102
Regular price $3,900.00 Sale price $1,500.00 Save $2,400
/
Only 24 items in stock!
  • We currently only offer shipping to addresses within the US
  • Free returns
  • Sustainably made
  • Secure payments

Features:Storage Tank
Material: Stainless Steel
Max Temp. (f): 250
Down Stem Connection Type (in): (1) Tri Clamp 1.5
Down Stem Length (in): 47.8
Recovery Line Connection Type (in): (2) Tri Clamp 1.5
Heat Exchanger Connection Type (in): (2) Tri Clamp 1.5
Coil Count: 40
Jacket Connection Type (in): (2) Tri Clamp 1.5
Lid Connection Type (in): (1 ) Tri Clamp 8
Gasket Type (in): Viton 6
Vessel Width (in): 18.1
Vessel Height (in): 50.6
Safety Feature 1 (type): (4) Lock in Breaks
Sight Glass Material (in): (2) Borosilicate 3.3
Sight Glass Gasket Material (in): (2) PTFE 2
Mobility Type: (4) TPU Casters

Specifications: Inner Chamber
Inner Diameter (in): 15.7
Wall Density (mm): 5
Volume (Cu In): 9210.35
Volume (Cu ft): 767.53
Fluid Capacity (L): 150.79
Fluid Capacity (Gal): 39.89
Butane Capacity (LBS): 162.96 - 203.70
Propane Capacity (LBS): 129.01 - 161.27
Biomass Capacity (LBS): 47.53 - 67.90
3A Sieve Capacity (LBS): 271.60
Nugget Ice Capacity (LBS): 217.28

Specifications: Jacket
Inner Diameter (in): 18.1
Wall Density (mm): 3
Volume (Cu In): 3168.05
Volume (Cu ft): 264.00
Fluid Capacity (L): 51.87
Fluid Capacity (Gal): 13.72
Butane Capacity (LBS): 56.05 - 70.06
Propane Capacity (LBS): 44.38 - 55.47
Biomass Capacity (LBS): 16.35 - 23.36
3A Sieve Capacity (LBS): 93.42
Nugget Ice Capacity (LBS): 74.74

Specifications: Condenser
Tube Diameter (in): 0.375
Wall Density (mm): 3
Volume (Cu In): 97.10
Volume (Cu ft): 8.09
Fluid Capacity (L): 1.59
Fluid Capacity (Gal): 0.42
Butane Capacity (LBS): 1.72 - 2.15
Propane Capacity (LBS): 1.36 - 1.70
Biomass Capacity (LBS): 0.50 - 0.72
3A Sieve Capacity (LBS): 2.86
Nugget Ice Capacity (LBS): 2.29
